Wireless LAN / Bluetooth Mini-PCI Express [Qcom Combo ZQ802XRACB] -- With Pigtails/Antennas --

Wireless LAN / Bluetooth Mini-PCI Express [Qcom Combo ZQ802XRACB] -- With Pigtails/Antennas --
  • Half-Height Mini-PCIe
  • Long term available !
  • Realtek RTL8821AE !

Qcom WIFI+BT Combo Card 802.11 b/g/n/ac Wireless LAN and Bluetooth 4.0 + BLE Combo Half Mini Card

The ZQ802XRACB (successor model of Q802XKN3B) is designed to provide wireless LAN and Bluetooth function on a small form factor with PCI Express interface for wireless LAN and USB interface for Bluetooth to the host system.

Key Specifications/Special Features:

  • Combo module compatible with IEEE802.11 a/b/g/n/ac draft2.0 1T1Rand BT4.0 + BLE.
  • Complies with PCI express Base specification revision 1.1 for WLAN
  • Complies with USB1.1 specification for Bluetooth
  • PCIe LTR/OBFF/L1.Off state supported
  • 72.2Mbps receive PHY rate and 72.2 M [more]

    Share

47.95 EUR
incl. 19% VAT, plus shipping
In Stock (66 pcs)

5 von 5 Sternen
2 ratings
Add to cart

Qcom WIFI+BT Combo Card 802.11 b/g/n/ac Wireless LAN and Bluetooth 4.0 + BLE Combo Half Mini Card

The ZQ802XRACB (successor model of Q802XKN3B) is designed to provide wireless LAN and Bluetooth function on a small form factor with PCI Express interface for wireless LAN and USB interface for Bluetooth to the host system.

Key Specifications/Special Features:

  • Combo module compatible with IEEE802.11 a/b/g/n/ac draft2.0 1T1Rand BT4.0 + BLE.
  • Complies with PCI express Base specification revision 1.1 for WLAN
  • Complies with USB1.1 specification for Bluetooth
  • PCIe LTR/OBFF/L1.Off state supported
  • 72.2Mbps receive PHY rate and 72.2 Mbps transmit PHY rate using 20Mhz bandwidth
  • 150Mbps receive PHY rate and 150Mbps transmit PHY rate using 40MHz bandwidth
  • 433.3Mbps transmit/receive PHY rate using 80Mhz bandwidth
  • 802.11ac Draft 2.0 compatible WLAN
  • 802.11e QoS Enhancement(WMM)
  • 802.11i (WPA, WPA2)
  • Open, shared key, and pair-wise key authentication services
  • WAPI supported
  • Frame aggregation for increased MAC efficiency (A-MSDU, MPDU)
  • Low latency immediate High-Throughput Block Acknowledgement (HT-BA)
  • PHY-level spoofing to enhance legacy compatibility
  • Multi MAC ID support with Fast Channel switch
  • Channel management and co-existence
  • Transmit Opportunity (TXOP) Short Inter-Frame Space (SIFS)bursting for higher multimedia bandwidth
  • WiFi Direct supports wireless peer to peer applications
  • Supports Wake-On-Wlan via Magic Packets and Wake-up frames
  • Supports S3/S4 AES/TKIP group key update
  • Supports Win8 Network List Offload
  • CCA on secondary through RTS/ CTS handshake
  • Supports TCP/UDP/IP check sum offload
  • Integrated MCU to execute Bluetooth protocol stack

Data sheet Download (PDF)
Data sheet Print view
Specifications Download (PDF)
Drivers (Windows) Download
Please login for creating product ratings.
Your rating:

Please tell us your opinion. Rate the product on a scale from 1 to 5. A value of 5 means the best possible rating. If you want you also can leave a comment.

Your ratings are honored on many ways. Your report will help other customers to better judge about the products. And you can benefit from reports other customers are giving.

In addition we credit 0.50 EUR for each given rating with comment and 1.00 EUR for each given rating with comment (more than 150 characters) on your account. The credit will be substracted automatically on your next order !

We reserve us the right to delete given comments (for example on attempts to give comments with senseless content, copying of other comments, inserting of foreign content, abusing the system for financing orders). "Fair-use-policy" does apply (as of rule of thumb you should give comments for products which you have purchased already. And your credit account only in rare cases will have 2 or even 3 digits). The credit can only be withdrawn by placing an order. It is not possible to get the credit cash or transferred in an other way.

Customer ratings: 5 von 5 Sternen
Average rating, based on 2 ratings
4 von 5 Sternen from rysanek am 07.03.2017 | See all my comments

Wir haben 2 Sätze eingekauft. Die Karte mit Realtek Chip sieht überraschend gut aus, aber die Antennen und Pigtails vertraue ich nicht... die Pigtails sind dünn und lang, und die Koax-Stecker/Buchsen sind die "normale" SMA Variante, typische für GSM, eher als WiFi. Für WiFi würde ich die "reverse" SMA Variante erwarten. Sollte ich die Antennen vertrauen, daß sie wirklich für WiFi inkl. 5 GHz geeignet sind? Ich habe leider keinen 6GHz Analysator um die Antennen selber zu messen. Glücklicherweise kann man passende Pigtails und Antennen selber wählen/einkaufen, die blosse Karte wird von CarTFT auch allein verkauft (Art.Nr. 1324).

5 von 5 Sternen from Geupel am 20.08.2015 | | See all my comments

super immer wieder !!!!
